PROFILE
PROJECTORS
PRO300H / PRO300T
-
Fine ground glass screen of 300 mm clear aperture.
-
Light travels horizontally in horizontal model while it is projected vertically in table top model.
-
Rotating screen with 360 degrees markings with Vernier scale with 1’ least count.
-
Cross-Wire making on screen glass.
-
20X Magnification
-
Diascopic / Contour system : Shadow is projected on the screen.
-
Episcopic : Job surface illuminated.
-
X-Y stage measuring top size 360mm X 200mm. Made in CI and Linear Bearings for durability and smooth operations.
-
230V AC single phase.
-
5 micron least count DRO. Linear, Arc/Radius, Angular measurements, PC connectivity.
-
Screen Diameters available : 200mm, 300mm, 450mm, 600mm
Auto-L-Check
A unique equipment designed, developed and manufactured specifically for Automobile Bulb manufacturers. This instrument is used to take various dimensional measurements of automobile bulb, especially LCL of the bulb.
-
Three fine ground glass screens of 200 mm clear aperture each.
Rotating screens with 3600 markings with 2' least count vernier scales.
Cross-wire makings on screen glasses. -
10X Magnification
Diascopic/Contour system : Shadow is projected on left and right screens.
Episcopic : Job surface illuminated at center screen. -
Specially designed holders for each auto bulb, made in alloy for durability.
150 rotation of holder in left and right direction for measuring tilt angle of filaments.
A default standard LCL (Light Center Length) is set.
Moving the scales along the screens, measures the the deviation in LCL
Use center screen to measure shield angle for bulbs like S2 or R2.
OPG Head
-
Specially designed Optical Profile Grinder Heads. as replacements, fitted on profile grinders. Upto 7.8mm job can be checked very easily.
-
Fine ground glass screen of 200mm clear aperture.
-
25X Standard Magnification.
-
The main illumination system of 12V, 55W halogen lamp is fitted at the bottom of OPG head, inside the body.
